PBN Tube

Pyrolytic Boron Nitride (PBN) tubes are high-purity, high-strength ceramic tubes made by chemical vapor deposition. They have excellent thermal and electrical insulation properties, low dielectric loss, and high thermal conductivity.

Inquire
Product Description

Features & Benefits

  • High purity and chemical inertness
  • High strength and hardness
  • High thermal conductivity and stability at high temperatures
  • Low dielectric constant and loss tangent
  • Excellent thermal and electrical insulation properties
  • Enables high-temperature processing of materials without contamination
  • Lowers the risk of sample damage due to thermal stress
  • Improves the efficiency and accuracy of high-temperature experiments
  • Provides a stable and reliable platform for high-temperature electronic devices

Markets & Applications

  • Semiconductor manufacturing, including MOCVD, MBE, and LPCVD
  • High-temperature processing and annealing of metals, ceramics, and glasses
  • Research and development of high-temperature materials and coatings
  • Aerospace and defense applications, such as thermal management and electronic packaging
  • High-temperature electronic devices, including sensors, transistors, and power electronics.
Property Value
Thermal conductivity 25-300 W/mK
Coefficient of thermal expansion (CTE) 2.3-2.7 ppm/K
Density 1.9-2.1 g/cm³
Hardness 7-9 Mohs
Maximum service temperature 1,800-2,200°C
Dielectric constant 2.2-3.6
Transparency Transparent in IR
Chemical stability Chemically inert
Refractive index 1.7-1.9
